Inset Taxiway Edge Light
PB-Q-2Application:
Type I-III airport taxiway, apron regionConstruction and features:
-The main parts are made from special cast Aluminium alloy.
-Double enclosure structure is used to protect the incoming cable and inner body, with good water tightness.
-The fitting can withstand static loading of 31.7kg/m2.
-Capable of withstanding 1380kPa of instantaneous hydraulic pressure in water tightness test without seepage.
-Capable of withstanding multiple steel ball drop test (40J) on top surface without damaging/affecting the calibration of optical system and parts.
-The structure and parts are still in good condition after horizontal shear force test of 1361kg.
-Colour satisfy ICAO Annex 14 specification. -
Colour of light
Number of light bulb
Main beam coverage
Average Luminance Intensity (cd)
Bromine Tungsten light
Cable Entry
Weight(kg)
Horizontal
Elevated
Ampere (A)
Watts
(W)Blue
1
360°
0~6°
>2
6.6
48
Bottom
9
Side
